The YEMN017BA is a compact, high-performance 5G & GNSS 5-in-1 combo antenna designed for demanding industrial and commercial applications. Measuring Φ 103.5 mm × 42.5 mm, this low-profile, screw-mount antenna delivers ultra-wideband coverage from 600–6,000 MHz and supports legacy 3G, 2G, LTE Cat-M, and NB-IoT, ensuring maximum deployment flexibility.
Built for durability and harsh outdoor environments, the antenna features a rugged enclosure rated IP67, IP69K, and IK09, along with UV-resistant (UL 746c f1) and flame-resistant (UL 94 V-0) materials. It is fully compatible with Quectel RM520x Series modules.
Key Features
- 5-in-1 design
- 2 × 5G LMH antennas
- 2 × 5G MH / Wi-Fi antennas
- 1 × GNSS L1 & L5 antenna
- Ultra-wideband performance
- 5G/4G: 600–960 MHz, 1400–6000 MHz
- GNSS: 1164–1189 MHz, 1565–1606 MHz
- High efficiency & stable signal — optimized for reliable 5G and multi-band GNSS connectivity
- High isolation between antennas to reduce self-interference
- Terminated with SMA Male connectors
- Low-profile screw-mount design for discrete installations
- Rugged, outdoor-ready enclosure: IP67, IP69K, IK09
- Supports active GNSS operation
- Compatible with Quectel RM520x Series
Typical Applications
- Smart utilities & smart buildings
- Logistics systems & fleet management
- Industrial automation & robotics
- Public safety vehicles & buses
- Machinery telemetry & remote monitoring
- Engineering & Customization Support
Find more info on this product here: Data Sheet
Technical Specs
| Frequency Range | LMHs: 600–960 MHz, 1400–6000 MHz MHs: 1400–6000 MHz GNSS: 1164–1189 MHz, 1565–1606 MHz |
| Radiation Pattern | LMHs & MHs: Omni-directional GNSS: Directional |
| Polarization | LMHs & MHs: Linear GNSS: RHCP |
| Impedance | 50 Ω |
| Isolation | ≤ -6.3 dB |
Mechanical & Environmental
| Operation Temperature | -40 °C to +85 °C |
|
Storage Temperature |
-40 °C to +85 °C |
|
Ingress Protection (IP) Rating |
IP67 (After Installation) IP69K (After Installation) |
| Impact Protection (IK) Rating | IK09 |
|
RoHS & REACH Compliant |
Yes |
| Antenna Dimensions | Φ 103.5 mm × 42.5 mm |
| Weight | Typ. 220 g |
| Casing Material & Color | PC & Black |
| Connector Type | SMA Male |
| Mounting Type | Screw Mounting (M20) |
| Cable Type & Color & Length |
LMHs & MHs: RG405 Black & 300 mm GNSS: RG174 Black & 300 mm |
| Housing UV Resistant | UL 746c f1 |
| Housing Flame Rating | UL 94 V-0 |
